designed to feel the wave.
The U-Carve range
This range is designed to elevate three essential on-water sensations: glide, precision, and pure carving feel.
The U Carve range is built around a full-base concept, with a generous mounting footprint that delivers stiffness and a precise, dependable feel underfoot.
Its reduced span and refined tips concentrate the lift, freeing the roll completely for a more surfy, playful behavior and ultra-natural carving.
Despite this compact format, every detail of the profile - thickness, camber, transitions - has been refined to minimize drag and maximize glide and efficiency.
The result: a reactive, incisive, and fluid stabilizer that releases effortlessly while maintaining continuous, progressive support.
For riders who carve, connect, and draw lines
The range is aimed at both committed carving-focused wingers and demanding surf foilers seeking the perfect blend of connection, pumping efficiency, and expressive riding in the wave, plus downwinders who love drawing clean lines. It allows you to shape your turns in a fluid, instinctive and fully intuitive way, for a lively, efficient, and inspiring glide.
You get consistent drive, true connection to the wave, and rock-solid control at Vmax, further enhanced by the upturned tips acting as genuine winglets, reducing energy losses and unwanted movements at high speed.
At low speed, it still delivers: you keep lift, support, and a balanced, predictable feel, without ever “falling through” the foil.
That was the whole challenge
Achieving a foil that’s fully freed in roll, highly surfy, yet still efficient and reliable in the slowest sections.
Available sizes
The U Carve range comes in 130, 140, 150, and 160,each with specific outlines. The sweep angle evolves according to the level of pivot you want:
The 160, with a straighter outline, delivers tighter turns and excellent maneuverability in small conditions, while the smaller sizes, with increased sweep, offer more drive and stability in faster, more open lines.Each rider can choose the exact model that best suits their weight, style, and preferred conditions.
In short, the U Carve is a fusion of performance, glide, and feel - a natural, precise, intuitive behavior that offers as much freedom as stability.
A design dedicated to pure surf carving, designed to feel the wave, not fight it.
Technical information
U carve 130
| Surface | 130 cm2 |
|---|---|
| span | 360 mm |
| Aspect ratio | 10 |
| Chord max. | 68 |
| Thickness max. | 5 |
| Construction | HR Carbon + HM Carbon / Monolithic |
| Screw size | 12mm Torx 30 |
Choose your U Carve Stabilizer
 130 229,00€ |  140 229,00€ |  150 229,00€ |  160 229,00€ | |
|---|---|---|---|---|
| Area (cm²) | 130 | 140 | 150 | 160 |
| Wingspan (mm) | 360 | 375 | 390 | 400 |
| Aspect ratio | 10 | 10 | 10 | 10 |
| Max chord (mm) | 68 | 72 | 76 | 80 |
| Max thickness (mm) | 5 | 5 | 5 | 5 |
| Screw size | 12mm Torx 30 | 12mm Torx 30 | 12mm Torx 30 | 12mm Torx 30 |
| Weight (g) | 100 | 100 | 100 | 100 |
| Construction | HR Carbon + HM Carbon / Monolithic | HR Carbon + HM Carbon / Monolithic | HR Carbon + HM Carbon / Monolithic | HR Carbon + HM Carbon / Monolithic |
- Area (cm²)
- 130
- Wingspan (mm)
- 360
- Aspect ratio
- 10
- Max chord (mm)
- 68
- Max thickness (mm)
- 5
- Screw size
- 12mm Torx 30
- Weight (g)
- 100
- Construction
- HR Carbon + HM Carbon / Monolithic
- Area (cm²)
- 140
- Wingspan (mm)
- 375
- Aspect ratio
- 10
- Max chord (mm)
- 72
- Max thickness (mm)
- 5
- Screw size
- 12mm Torx 30
- Weight (g)
- 100
- Construction
- HR Carbon + HM Carbon / Monolithic
- Area (cm²)
- 150
- Wingspan (mm)
- 390
- Aspect ratio
- 10
- Max chord (mm)
- 76
- Max thickness (mm)
- 5
- Screw size
- 12mm Torx 30
- Weight (g)
- 100
- Construction
- HR Carbon + HM Carbon / Monolithic
- Area (cm²)
- 160
- Wingspan (mm)
- 400
- Aspect ratio
- 10
- Max chord (mm)
- 80
- Max thickness (mm)
- 5
- Screw size
- 12mm Torx 30
- Weight (g)
- 100
- Construction
- HR Carbon + HM Carbon / Monolithic
U Carve Stabilizer
- Warranty : All our products come with a 2-year warranty.
- After-sales service : Free returns within 15 days
AFS Product Expert
Need help choosing your equipment?
We are here to provide you with comprehensive answers and advice to help you make the right choice.
Make an appointment by telephone
Need advice?
An AFS expert helps you pick the right size and setup.
Quick replies, Monday to Friday.
In the box
3 items- 1 U Carve StabilizerThe size you choose above.
- 1 Stabilizer coverProtects the stabilizer in transit.
- 3 Mounting screws · M6×12Ready to fit.
