PUMP FOIL

Pump foiling means flying your foil on your own movement. No sail, no motor. You can start from a dock, a ramp, a boat or the beach. Starting from a dock is called a dockstart. On this page, you will find the AFS front wings, masts and boards for your riding, and the one setup we recommend for your weight. For technique, read our guide Mastering the art of pumping foil.

Find your pump foil setup

Enter your weight and your level in the foil finder. We recommend a front wing, a mast and a board: one setup, the one we would put together for your riding. Your level changes the board.

• Beginner: you have not yet linked a flight off the dock.
• Intermediate: you link a few pumps after the start.
• Expert: you pump for a long time without touching down.

Which front wing for pump foiling and dockstart?

For pump foiling, we look at how easy a wing is to pump first, then at lift. A large front wing makes the motion smoother and takes less effort than a small one. We recommend the Enduro GLT, or the Enduro 1300 if you are lighter. Both have an aspect ratio of 11. To understand what that means, read What is aspect ratio?

The Enduro GLT comes in one size: 1,600 cm² (248 sq in), with a 1,323 mm (52.1 in) wingspan. The Enduro 1300 has a 1,190 mm (46.9 in) wingspan.

Front wing size by rider weight

For your riding, we aim for 1,633 cm² at 75 kg (165 lb). Add 14 cm² for every kilo above that (about 6.4 cm² per lb), and take it off below.

Your weight	Target area	Front wing we recommend
55 kg (121 lb)	1,353 cm²	Enduro 1300
60 kg (132 lb)	1,423 cm²	Enduro 1300
65 kg (143 lb)	1,493 cm²	Enduro GLT
70 kg (154 lb)	1,563 cm²	Enduro GLT
75 kg (165 lb)	1,633 cm²	Enduro GLT
80 kg (176 lb)	1,703 cm²	Enduro GLT

From about 73 kg (161 lb), the target area goes above 1,600 cm². The Enduro GLT is still the largest wing we recommend for your riding. The heavier you are, the bigger the gap, and the more effort the dockstart takes. Above 90 kg (198 lb), book a free call with an AFS expert before you choose.

What mast length for dockstart?

For dockstart, we recommend an 80 cm (31.5 in) mast. With the Enduro GLT or the Enduro 1300, go with the UHM mast, 80 cm. We do not recommend the UHM Skinny mast with these large wings. To compare our mast ranges, read How to choose the right AFS carbon mast? or use the mast finder.

Which pumping foil board?

A pump foil board is short and light. AFS makes two.

• SK8: 16 L, 95 × 44 cm (37.4 × 17.3 in), 2.3 kg (5.1 lb), fiberglass and PVC sandwich, EVA pad. We recommend it to get started.
• Dock-star: 7 L, 83 × 38.5 cm (32.7 × 15.2 in), 1.7 kg (3.7 lb), prepreg carbon with a Corecell core, deck tilted forward. We recommend it once you link your flights.

To see every AFS board, go to all boards.

How do you pump after a dockstart?

Pumping always starts once you are up on the foil. Dockstart is a good way to learn, because you start from a platform. Then the rule is simple: unweight to let the foil rise, then press on your front foot to drop and gain speed. A long, smooth motion uses less energy than fast, short pumps. At first, avoid tight turns: you lose your speed.

For foot pressure and rhythm in detail, read our pumping foil guide.

On video, how to set up a pump foil for dockstart, with Hadou Brunner (Wing Foil Pro Center). The video is in French.

Why an AFS foil for pump foiling?

• The Enduro GLT weighs 1.4 kg (3.1 lb), with a 162 mm (6.4 in) chord and a 19 mm (0.75 in) thickness.
• Our foils are made in France, at our factory in Brittany.

All our products come with a 2-year limited warranty. For returns, see our terms of sale.

Beyond pump foiling

Pumping also helps you catch a wave in foil surfing (prone foiling), link swells in downwind or get going again in wing foiling. If you want to ride waves, read Getting started with foil surfing.

Pump foil FAQ

What is pump foiling?

Pump foiling (or foil pumping) means moving your board and foil forward with your body. There is no sail, no kite and no motor. Starting from a dock is called a dockstart.

Can you pump foil without a dock?

Yes. You can start from a dock, a ramp, a boat or the beach.

What size front wing do you need for pump foiling?

We aim for 1,633 cm² for a 75 kg (165 lb) rider. In practice, we recommend the Enduro GLT from 62 kg (137 lb), and the Enduro 1300 below that.

What mast length is best for pump foiling and dockstart?

80 cm (31.5 in). With the Enduro GLT or the Enduro 1300, go with the UHM mast, 80 cm.

What size board do you need for pump foiling?

To get started, we recommend the SK8 (16 L). Once you link your flights, move to the Dock-star (7 L).

How do you learn to pump foil?

Start with a dockstart: you begin from a platform. Use a large front wing, keep your pumps long and smooth, and avoid tight turns at first.

Where can I find used pump foil gear?

On the AFS marketplace, where riders sell their gear.

Know your weight and your level? Open the foil finder: we recommend your pump foil setup. For technique, read our guide to mastering pumping foil.
